PROFESSIONAL-CLOUD-NETWORK-ENGINEER Online Practice Questions and Answers

Your company just completed the acquisition of Altostrat (a current GCP customer). Each company has a separate organization in GCP and has implemented a custom DNS solution. Each organization will retain its current domain and host names until after a full transition and architectural review is done in one year. These are the assumptions for both GCP environments.

1.

Each organization has enabled full connectivity between all of its projects by using Shared VPC.

2.

Both organizations strictly use the 10.0.0.0/8 address space for their instances, except for bastion hosts (for accessing the instances) and load balancers for serving web traffic.

3.

There are no prefix overlaps between the two organizations.

4.

Both organizations already have firewall rules that allow all inbound and outbound traffic from the 10.0.0.0/8 address space.

5.

Neither organization has Interconnects to their on-premises environment.

You want to integrate networking and DNS infrastructure of both organizations as quickly as possible and with minimal downtime.

Which two steps should you take? (Choose two.)

A. Provision Cloud Interconnect to connect both organizations together.

B. Set up some variant of DNS forwarding and zone transfers in each organization.

C. Connect VPCs in both organizations using Cloud VPN together with Cloud Router.

D. Use Cloud DNS to create A records of all VMs and resources across all projects in both organizations.

E. Create a third organization with a new host project, and attach all projects from your company and Altostrat to it using shared VPC.

You have the following firewall ruleset applied to all instances in your Virtual Private Cloud (VPC):

You need to update the firewall rule to add the following rule to the ruleset:

You are using a new user account. You must assign the appropriate identity and Access Management (IAM) user roles to this new user account before updating the firewall rule. The new user account must be able to apply the update and view firewall logs. What should you do?

A. Assign the compute.securityAdmin and logging.viewer rule to the new user account.Apply the new firewall rule with a priority of 50.

B. Assign the compute.securityAdmin and logging.bucketWriter role to the new user account. Apply the new firewall rule with a priority of 150.

C. Assign the compute.orgSecurityPolicyAdmin and logging.viewer role to the new user account. Apply the new firewall rule with a priority of 50.

D. Assign the compute.orgSecurityPolicyAdmin and logging.bucketWriter role to the new user account. Apply the new firewall rule with a priority of 150.

You recently deployed Cloud VPN to connect your on-premises data canter to Google Cloud. You need to monitor the usage of this VPN and set up alerts in case traffic exceeds the maximum allowed. You need to be able to quickly decide whether to add extra links or move to a Dedicated Interconnect. What should you do?

A. In the Network Intelligence Canter, check for the number of packet drops on the VPN.

B. In the Google Cloud Console, use Monitoring Query Language to create a custom alert for bandwidth utilization.

C. In the Monitoring section of the Google Cloud Console, use the Dashboard section to select a default dashboard for VPN usage.

D. In the VPN section of the Google Cloud Console, select the VPN under hybrid connectivity, and then select monitoring to display utilization on the dashboard.

Your company is planning a migration to Google Kubernetes Engine. Your application team informed you that they require a minimum of 60 Pods per node and a maximum of 100 Pods per node Which Pod per node CIDR range should you use?

A. /24

B. /25

C. /26

D. /28

You are disabling DNSSEC for one of your Cloud DNS-managed zones. You removed the DS records from your zone file, waited for them to expire from the cache, and disabled DNSSEC for the zone. You receive reports that DNSSEC validating resolves are unable to resolve names in your zone.

What should you do?

A. Update the TTL for the zone.

B. Set the zone to the TRANSFER state.

C. Disable DNSSEC at your domain registar.

D. Transfer ownership of the domain to a new registar.

You create multiple Compute Engine virtual machine instances to be used as TFTP servers.

Which type of load balancer should you use?

A. HTTP(S) load balancer

B. SSL proxy load balancer

C. TCP proxy load balancer

D. Network load balancer

You have provisioned a Dedicated Interconnect connection of 20 Gbps with a VLAN attachment of 10 Gbps. You recently noticed a steady increase in ingress traffic on the Interconnect connection from the on-premises data center. You need to ensure that your end users can achieve the full 20 Gbps throughput as quickly as possible. Which two methods can you use to accomplish this? (Choose two.)

A. Configure an additional VLAN attachment of 10 Gbps in another region. Configure the on-premises router to advertise routes with the same multi-exit discriminator (MED).

B. Configure an additional VLAN attachment of 10 Gbps in the same region. Configure the on-premises router to advertise routes with the same multi-exit discriminator (MED).

C. From the Google Cloud Console, modify the bandwidth of the VLAN attachment to 20 Gbps.

D. From the Google Cloud Console, request a new Dedicated Interconnect connection of 20 Gbps, and configure a VLAN attachment of 10 Gbps.

E. Configure Link Aggregation Control Protocol (LACP) on the on-premises router to use the 20-Gbps Dedicated Interconnect connection.

You have an application that is running in a managed instance group. Your development team has released an updated instance template which contains a new feature which was not heavily tested. You want to minimize impact to users if there is a bug in the new template.

How should you update your instances?

A. Manually patch some of the instances, and then perform a rolling restart on the instance group.

B. Using the new instance template, perform a rolling update across all instances in the instance group. Verify the new feature once the rollout completes.

C. Deploy a new instance group and canary the updated template in that group. Verify the new feature in the new canary instance group, and then update the original instance group.

D. Perform a canary update by starting a rolling update and specifying a target size for your instances to receive the new template. Verify the new feature on the canary instances, and then roll forward to the rest of the instances.

You are configuring a new application that will be exposed behind an external load balancer with both IPv4 and IPv6 addresses and support TCP pass-through on port 443. You will have backends in two regions: us-west1 and us-east1. You

want to serve the content with the lowest possible latency while ensuring high availability and autoscaling.

Which configuration should you use?

A. Use global SSL Proxy Load Balancing with backends in both regions.

B. Use global TCP Proxy Load Balancing with backends in both regions.

C. Use global external HTTP(S) Load Balancing with backends in both regions.

D. Use Network Load Balancing in both regions, and use DNS-based load balancing to direct traffic to the closest region.

You are designing a hub-and-spoke network architecture for your company's cloud-based environment. You need to make sure that all spokes are peered with the hub. The spokes must use the hub's virtual appliance for internet access.

The virtual appliance is configured in high-availability mode with two instances using an internal load balancer with IP address 10.0.0.5. What should you do?

A. Create a default route in the hub VPC that points to IP address 10.0.0.5. Delete the default internet gateway route in the hub VPC, and create a new higher-priority route that is tagged only to the appliances with a next hop of the default internet gateway. Export the custom routes in the hub. Import the custom routes in the spokes.

B. Create a default route in the hub VPC that points to IP address 10.0.0.5. Delete the default internet gateway route in the hub VPC, and create a new higher-priority route that is tagged only to the appliances with a next hop of the default internet gateway. Export the custom routes in the hub. Import the custom routes in the spokes. Delete the default internet gateway route of the spokes.

C. Create two default routes in the hub VPC that point to the next hop instances of the virtual appliances. Delete the default internet gateway route in the hub VPC, and create a new higher-priority route that is tagged only to the appliances with a next hop of the default internet gateway. Export the custom routes in the hub. Import the custom routes in the spokes.

D. Create a default route in the hub VPC that points to IP address 10.0.0.5. Delete the default internet gateway route in the hub VPC, and create a new higher-priority route that is tagged only to the appliances with a next hop of the default internet gateway. Create a new route in the spoke VPC that points to IP address 10.0.0.5.
