1Y0-402 Online Practice Questions and Answers

Scenario: A Citrix Architect needs to design a new XenApp and XenDesktop environment.

The architect has determined the user groups and FlexCast model listed in the Exhibit during the high-level design. Click the Exhibit button to view the user group and FlexCast model details.

Which graphics protocol should the architect select for the highlighted group in the Exhibit?

A. Thinwire (Legacy)

B. Framehawk

C. Thinwire+

D. H.264

Scenario: A Citrix Architect needs to design a new XenDesktop environment for a client who does NOT currently have a Citrix environment. The project scope has NOT yet been determined, and the architect is about to start the Assess phase of the project.

In which order should the architect complete the four tasks of a typical assessment when following the Citrix methodology?

A. Define the organization, Define the user groups, Define the applications, Define the project team.

B. Define the user groups, Define the applications, Define the organization, Define the project team.

C. Define the project team, Define the organization, Define the user groups, Define the applications.

D. Define the organization, Define the project team, Define the user groups, Define the applications.

Scenario: A Citrix Architect is designing a XenDesktop environment. The Engineer group uses graphical applications which require the use of AMD hardware shared virtualized GPU. Which two hypervisors can the architect select? (Choose two.)

A. XenServer 6.5

B. VMware vSphere 5.5

C. XenServer 7.0

D. VMware vSphere 6.0

E. Microsoft Hyper-V Server 2012 R2

Scenario: A Citrix Architect is designing an environment for a large company. The company has identified

the following user groups and requirements.

Product Managers - Typically, they work from inside the company network but are able to work from home.

They need to use a variety of standard productivity and web-based SaaS applications.

Field Sales Engineers - They frequently work with mobile devices and tend to access the environment

externally. They need access to sales tools and the front-end of the customer database.

Web Developers - Internal and remote workers who use specialized hardware with a graphics card to

handle resource-intensive applications.

Which FlexCast model should the architect assign to Field Sales Engineers?

A. Published Apps

B. Hosted Applications

C. Hosted VDI

D. Published Desktops

Scenario: A Citrix Architect has designed an active/passive XenApp and XenDesktop environment for a

customer, where the passive datacenter serves as the disaster recovery datacenter for all users.

The following has been configured:

NetScaler Global Server Load Balancing (GSLB) to provide single URL direction to the active datacenter.

GSLB has health monitors configured for the load balanced servers.

NetScaler Gateways are on both datacenters.

NetScaler load balancing occurs for StoreFront and Delivery Controller XML services.

A single XenApp and XenDesktop Site exists.

Four Delivery Controllers are members of the Site.

Two Delivery Controllers are members of the primary zone in the active datacenter.

Two Delivery Controllers are members of the satellite zone in the passive datacenter.

SQL is deployed in the active datacenter.

Local Host Cache is enabled.

Two StoreFront servers are deployed in each datacenter aggregating resources from the Delivery

Controllers in the respective datacenter.

Virtual Delivery Agent (VDA) machines are deployed in both datacenters and configured to register with

Delivery Controllers in their zone.

What would happen if the SQL Server in the primary datacenter were turned off?

A. VDA machines from the primary datacenter would register with the Delivery Controllers in the passive datacenter.

B. GSLB will NOT identify that the SQL Server is down and sessions cannot launch.

C. StoreFront in the primary datacenter would still be able to launch sessions.

D. GSLB will start redirecting connections to the secondary datacenter.

Scenario: A Citrix Architect needs to implement a new XenDesktop environment for an engineering company. The IT department has purchased 1,000 XenDesktop Enterprise licenses. They will deploy Microsoft Office productivity applications to all users. Users access XenApp sessions from company offices using thin client devices and remotely through NetScaler Gateway using personal devices.

The company requires IT to produce a report of all XenApp connection failures for the previous year.

Which two actions does the architect need to take to support these requirements? (Choose two.)

A. Purchase XenDesktop Platinum licenses.

B. Purchase NetScaler Gateway Universal licenses.

C. Configure GroomSessionsRetentionDays to 365 days.

D. Implement NetScaler Management and Analytics System (MAS).

E. Configure GroomFailuresRetentionDays to 365 days.

Scenario: The IT team of a company needs to migrate to Microsoft Azure and has asked a Citrix Architect for a solution that offers protection from datacenter level failures.

What should the architect recommend the IT team create in Microsoft Azure?

A. Availability set with update domain

B. Availability set with fault domain

C. Resource group

D. Availability zones

Scenario: A Citrix Architect needs to design a new XenApp and XenDesktop environment.

The following Control Layer security requirements have been identified:

For security reasons, it is unacceptable to use default ports for FMA Services.

Access to PowerShell and Citrix Studio for management will be restricted to management workstations by

granular firewall rules.

Which command-line interface executable should the architect run to ensure that all Control Layer security

requirements are met?

A. BrokerService.exe 璙daPort 8081 璚ISSLPort 8083 璖DKPort 8083 瑿onfigureFirewall

B. BrokerService.exe 璙daPort 443 璚ISSLPort 443 璖DKPort 443 瑿onfigureFirewall

C. BrokerService.exe 璙daPort 80 璚ISSLPort 80 璖DKPort 8083 瑿onfigureFirewall

D. BrokerService.exe 璙daPort 8081 璚ISSLPort 8082 璖DKPort 8083 瑿onfigureFirewall

A Citrix Architect needs to conduct a capabilities assessment for an organization that wants to design and build a new XenApp and XenDesktop environment.

Which four capabilities will directly influence whether users are currently able to connect to an alternative datacenter if the primary datacenter becomes unavailable? (Choose four.)

A. Disaster recovery plan and implementation

B. Existing XenApp and XenDesktop environments

C. Current hypervisor and storage solutions

D. Existing access infrastructure

E. Windows Server and Active Directory environment

F. Client devices and mobility requirements

G. Network architecture

Scenario: A Citrix Architect needs to design a new XenApp and XenDesktop environment. Provisioning Services has been selected for image management. The Provisioning Services vDisk store requires high fault tolerance and the ability to support dual drive failure.

Which RAID level could the architect use for the Provisioning Services vDisk store?

A. RAID 6

B. RAID 5

C. RAID 0

D. RAID 1
